Pentair Pelican Salt-Based Water Softener System

PENTAIR WHOLE HOUSE WATER SOFTENING SYSTEMS

Reduce the worry that hard water can cause.

Hard water can be a nuisance. Your dishes sport spots, and your laundry may come out stiff and dull. Dry skin and hair are common complaints. Inefficient appliance operation may lead to increased water and energy costs.

A Pentair Whole House Water Softening System reduces the calcium,
magnesium, and other dissolved minerals that cause hard water before they
enter your home. So you can enjoy clearer dishes, softer clothes, softer
skin and hair, and lower water and energy bills.

PROACTIVE PROTECTION
Hard water can create more than just a nuisance - it can cause higher water bills, wear out fabrics and deteriorate pipes. Pentair water softening systems eliminate dissolved minerals to help prevent such disturbances.

CERTIFIED PROTECTION
Pentair's whole house water softening systems are fuss-free with their electronic control that is user-friendly to configure. An automatic bypass function ensures continuous water supply to the house during the regeneration process.

BETTER WATER FROM PENTAIR
When it comes to water, every home and every family is different.
Whether you’re on a well or you get city water, it might be very
different across town, or even across the street. At Pentair, we offer
water treatment solutions that can be tailored to your needs. So you get
the clearer, fresher water you want. And the peace of mind you need.

FEATURES & BENEFITS

• Reduces minerals so your clothes and dishes come out clean, your appliances run smooth, and your water tastes great
• Automatically regenerates only when necessary, so it uses less salt which saves you time and money
• Self-cleaning design keeps the system running smoothly with little maintenance, so you don’t have to think about it

• Simple, electronic system for easy programming; maintains settings during power outages
• Automatic bypass for uninterrupted water flow to the home during regeneration
• Singular, rotary disc seal for longer life and lower maintenance
• Self-cleaning brine injector reduces maintenance
• Safety valve prevents brine tank overflow
• Highly-efficient, chlorine-resistant resin for longer life
• Demand-initiated system regenerates when necessary, based on water usage, saving salt and water
• 1.0, 1.5 and 2.0 cubic foot capacities available to meet household demand requirements

Specifications

VALVE SPECIFICATIONS
Valve Body Glass-Filled Thermoplastic
Rubber Components Compounded For Cold Water
Operating Pressure 20 - 120 psi (1.38 - 8.27 bar)
Water Temperature 40° - 100°F (4.4° - 38°C)
Ambient Temperature 40° - 100°F (4.4° - 38°C)

POWER REQUIREMENTS
Input Supply Frequency 50 or 60 Hz
Motor Input Voltage 24 Volt – DC

Controller System Power Consumption 3 Watts Average
Transformer Input Options 115 Volt – AC 50/60 Hz
Transformer Output Voltage 24 Volt - AC 500 mA

CYCLE INFORMATION
Downflow/Upflow Downflow Only
Adjustable Cycles Yes
5 Cycle Valve 1) Service/Home
2) Backwash
3) Brine Draw
4) Fast Rinse
5) Brine Fill

VALVE CONNECTIONS
Tank Thread 2-1/2" – 8, Male
Drain Line 3/4" NPT, Female
Brine Line 3/8" Tube Fitting
In/Out Bypass Valve Included
Drain Line Elbow Fitting 1/2" Hose Barb Included
In/Out Plumbing
Connection 3/4" NPT,
Male Plastic Fittings
